6600-726 Sundance® Circuit Board w/Circ Pump Only (LX-15)



SKU: 6600-726

MPN: 6600-726

UPC: 680576081162

Manufacturer: Sundance® Spas

Warranty: 1 year with manufacturer

See 6600-726 Schematic and 6600-726 Topside Board Configuration

Jacuzzi/Sundance® 6600-726 Circuit Board w/Circ Pump (LX-15)

The 6600-726 Sundance® Circuit Board is a reliable and convenient solution for your spa’s circuit board replacement. It works with a Circ Pump (LX-15) and is cost-effective and efficient. Compatible with Sundance® spas, it offers seamless integration and long-term performance.

Compatible with the following Sundance® models:

  • 2003 – 2005 Sweetwater Board (Palermo, Bahia, and Cayman)
  • 2005 – 2006 780 Series Sundance® Spas (Palermo, Bahia, Cayman)
  • 2007+ 680 Hartford® and Hawthorne® models equipped with a Circulation Pump
  • 2007+ 780 Hamilton, Chelsee®, Certa and Camden® (1-pump)
  • 2008+ 1-pump 680 Burlington® model equipped with a circulation pump.
  • Replaces the 6600-087 and 6600-088 Board 3.56, with circulation pump systems.
  • If your system has a 6600-087 and the EPROM chip begins with a 5 (such as REV 5.54), then you have a 6600-287 board.

Replacement for:

Note: This board only operates with a circulation pump. The alternative part for spas that doesn’t have a circulation pump is 6600-720.
