• NLA – contact us about a BP7 retrofit

SKU: BVS501

MPN: G4152

Model: BVS501Z

UPC: N/A

Manufacturer: Balboa Water Group®

Warranty: 1 year with manufacturer

The Balboa® System VS501Z 1 Pump with blower G4152 is a hot tub control system with a heater. It is part of the Value Series (VS) family, which incorporates Balboa’s patented M7™ technology for temperature and waterflow sensing. This system utilizes a universal control platform, enhancing reliability, ease of installation, and serviceability.

Features:

• US & Canadian safety approvals
• Runs 110 or 220 Volts
• Operates up to 2 pumps, plus an optional circ pump
• Custom designed plastic enclosure
• Integrated functionality
• State of the art design
• Designed for Easy Installation and Service
• M7™ flow and temperature sensors – replaces failure-prone, mechanical pressure/flow switch

Product specifications:

• Power Supply: 120/240 Volts (convertible)
• Pump 1: 1-Speed (circ) or 2-Speed
• Pump 2: Blower (1-speed)
• Panel Capacity: 2

Power Requirements:

• 120/240VAC, 60Hz, 16/32 Amps, Class A GFCI-protected service (Circuit Breaker rating = 20/40 Amps max.)
• 3 or 4 wires [hot, hot (optional), neutral, ground].

Replaced: VS501Z

Alternates: 54217, 54220

Documents:

• G4152Hot sheet
• G4152 Operation guide

Balboa Water Group a Worldwide Leader in Spa the Industry
