SKU: 56585

MPN: 56585

Model: BP501G3

UPC: N/A

Manufacturer: Balboa Water Group®

Warranty: 1 yr. with manufacturer

Product Description:
The product is a control system, most likely designed for use with a spa or hot tub. It features a chip with the number BP501G3 and offers Wi-Fi connectivity. Additionally, it supports all TP and SpaTouch topsides, indicating compatibility with various user interfaces or control panels.

Balboa Water Group® Circuit Board for control Panel TP800 (version 3.1 and later), TP600 (version 2.7 and later), TP400T (version 2.7 and later), TP400W (version 2.7 and later).

Product Specifications:

• Power Requirements:** The system operates on 240VAC, with a frequency of 50/60Hz. It requires a total of 48A of current. The power connection consists of four wires: two hot wires, a neutral wire, and a ground wire.
• GFCI Protection:** The system is equipped with Class A GFCI (Ground Fault Circuit Interrupter) protection. The circuit breaker is rated at a maximum of 60A.
• Alternate Setup:** For Setup 8 ONLY, there is an option to use either 3 or 4 wires. The configuration includes hot wires, optional additional hot wires, a neutral wire, and a ground wire.
• Hertz Detection:** The BP systems have the capability to automatically detect whether the input power is at 50Hz or 60Hz, ensuring compatibility with different electrical systems.

Please note that this product appears to be designed for electrical control and management within a spa or hot tub system, with an emphasis on safety through GFCI protection. If you have any specific questions or need further information, feel free to ask.

*All circuit boards will require correct board voltage install and component voltage set-up by moving the component wires on the board, in addition to setting dipswitches correctly. Some configuration on the topside may also be required. Please reference the wiring schematics*

Documents:56585  BP501G3 Tech Sheet

Alternate part number:

• 56961 / 56582

Notes:

• Not for circulation pumps
• Works with Balboa’s TP and SpaTouch™ Panels (The only exception is the TP200 & 500 cannot be used with more than 2 pumps)
