56297 Balboa® Circuit Board VS100Control Systems 120 volts
$299.00
DESCRIPTION
*All circuit boards will require correct board voltage install, and component voltage set-up by moving the component wires on the board, in addition to setting dipswitches correctly. Some configuration on the topside may also be required. Please reference the wiring schematics*
SKU: 56297
MPN: 56297
Model: VS100
UPC: N/A
Manufacturer: Balboa Water Group®
Warranty: 1 yr. with manufacturer Balboa®
Water Group® Circuit board used on Balboa® VS100, 120 Volts spa control systems.
Features:
- Chip Number: VS100C/VS100R1A
- Digital Duplex
Product Specifications:
- Cable: 8 Pin Phone style
- 3 Wires (Hot, Hot, Ground)
- 240VAC, 60HZ, 30Amps, Class A GFCI-protected service 40Amps
- Cord Connected Class A GFCI Required
- 3 Wires (Hot Neutral, Ground)
- 115-120VAC, 60HZ, 12Amps, Circuit Breaker Rating 15Aamps
Alternate: 56299, 3-60-6032
Replaces: 952994
*All circuit boards will require correct board voltage install and component voltage set-up by moving the component wires on the board, in addition to setting dipswitches correctly. Some configuration on the topside may also be required. Please reference the wiring schematics*
Note: Ensure you verify the chip number on your existing board. Keep in mind the crucial importance of not solely relying on the appearance of a circuit board when placing an order, as there are several boards that may appear similar but possess different software or chips.
