Key Features

• Stand-alone control and heating system
• Great replacement for discontinued Pinnacle systems
• Full-range thermostat for precise temperature control
• Integrated safety light and high-limit protection
• Includes circulation pump, heater, control pack, and mounting base
• Compatible with optional Auto-Fill and Auto-Drain kits (sold separately)
• Durable ABS base and stainless-steel heater flange

Specifications

• Voltage: 115V / 208V / 230V Single Phase
• Electrical Requirements: 4-wire feed with neutral
• Breaker Size: 20A / 40A / 50A (depending on voltage used)
• Heater Rating: 5.5 kW @ 230V
• Thermostat: Full-range adjustable
• Circulation Pump: 115V, 1/8 HP
• Heater Dimensions: 15″ length, 2″ OD, 304SS flange
• Assembled Dimensions: 13″ H × 27″ W × 15″ D

Included in the System

• Mechanical control pack
• 1/8 HP 115V circulation pump
• 5.5kW heater
• ABS equipment base
• Plumbing accessory/header kit
• Safety circuits and indicator outputs
• System interface module connection port

Additional Notes

• Circulation pump must be installed below water level (not self-priming).
• Auto Fill, Auto Drain, and Interface Keypad sold separately.
• Timer not included — For a 7-day timer, see part BES-6000T.
