SKU: 1016170

MPN: 1016170

Model: Ultimax

Manufacturer: Balboa Water Group®

Warranty: 1 yr. with manufacturer

Product Features:

• Compact 56-frame design.
• Dual-speed pump (can be configured for single-speed operation).
• Energy-efficient and operates with a whisper-quiet performance.
• Offers multiple options for multi-directional volute mounting, accommodating various plumbing configurations. How to Rotate a Pump Wet End
• All seals incorporate carbon ceramic with Viton elastomers, ensuring enduring performance even under prolonged exposure to heat and chemicals.

Product Specifications:

• Speeds: 2
• Motor Frame: 56Y
• Intake Size: 2″
• Motor Voltage: 230V
• Discharge Style: Side
• Amperage: 10 (High Speed) / 3.5 (Low Speed) (cord not included) (may be labeled 12/3.5)
• 3.0Horse Power (Often Labeled as 4.0 SPL HP)
• Discharge Size: 2″ (Side Discharge) (Outer Thread Diameter Is 3″)

Technical and Installation:

• Pump is shipped in the wet-end orientation shown. Please review How to Rotate a Pump Wet End
• Most pumps are shipped without a cord, and you will need to use your existing cord or purchase a new amp cord.
• Please see How to Wire a Spa Pump and the “related products” below to purchase replacement amp cord.

Also known as: PUUM2302582F, PUM22000927, 1016218, PUUMC2302582F, PUUMSC2502582FR, 1016200, PUUMC2302582FJ, PUUMSC2602582FDS, 1016236, 1016170, PUUMC2302582FR, 1016280, 1016172, 1016024-NHP, 1016019 (1 Speed), 1016173, 5235212-S, 1016025, 1016167, 1016278 (1 Speed), X320558, PUUMS2602582F, 1016205 (Niagara),  5235212-B, 1016174, 1016178 (1 Speed), 1016170 (1 Speed), PUUMSC2602582F, X320527, 1016014, X320528, PL388, X320375 (1 Speed), PL389, 1016205-NHP, 1016166, 1016195, 1016184, 1016026-NHP, 1056016 (Balboa), 1016020-NHP, 1015112 (1 Speed), 1016235, PL342, 1016230,1016194, 1016215
